Crawler-Mounted Hydraulic Water Well Rig Capable Of Drilling Up To 180m Deep
Machine Description
Introducing the RCF180S Small Water Well Drill - the perfect answer to all your drilling needs! Designed to be efficient and versatile, this compact crawler machine is an indispensable tool for contractors, farmers and water professionals.
With an outstanding drilling depth of up to 180 meters and a diameter capacity of 300 mm, the RCF180S can access deep groundwater sources, ensuring you get the essential resources you need. Whether you are drilling wells, boreholes or irrigating farmland, this equipment provides excellent performance and reliability.
The main benefit of the RCF180S is its high drilling efficiency. The equipment uses advanced technology to reduce drilling time without compromising on quality. Its simple design allows the operator to easily maneuver and control the drill, making it suitable for both experienced and novice drillers.
The RCF180S is also designed with energy efficiency in mind. Reducing fuel consumption and maximizing production, this small water well drill is an environmentally friendly choice for your drilling projects. Its rugged construction ensures durability, allowing you to rely on the equipment for many years to come.
In summary, the RCF180S small hole drill is a powerful, efficient, and adaptable tool that can meet a variety of drilling needs. Whether you are drilling for water, digging wells, or irrigating farmland, this equipment is your ideal solution. Invest in the RCF180S today and see how your drilling operations will improve!
Technical Parameters
| Bore diameter(hammer) | 90-300mm |
| Bore depth | 180m |
| Air consumption | 17-31m³/min |
| Air pressure | 1.7-2.5Mpa |
| Once-time advance length | 2.4m |
| Pipe diameter | 76mm/89mm |
| Pipe length | 2m |
| Push force | 4T |
| Lifting force | 15T |
| Max torque of rotary | 4000-4600Nm |
| Rotary speed | 45-65r/min |
| Mud Pump flow | 200L/min (option) |
| Feeding efficiency | 10-35m/h |
| Travel speed | 2.5Km/h |
| Climb ability | 30° |
| Dimension(L*W*H) | 2300×1200×1900mm |
| weight | 2700kg |
| Diesel engine | 77.3KW Yuchai engine |
Feature:
1.High Efficiency
Equipped with a hydraulic system and advanced drilling tools, the mini well drilling rig can drill up to 180m deep, making it an ideal choice for small water well projects.
2.Operating Easily
Its crawler chassis has excellent stability and maneuverability, allowing it to travel over rough terrain and difficult drilling conditions. The ergonomic control panel and user-friendly interface allow the operator to easily control and monitor the drilling progress.
3.Durability
Made of high-quality materials and advanced manufacturing processes, mini well drilling rig has a sturdy structure that can withstand harsh drilling conditions and can be used for many years with minimal maintenance.
Image Display
